Description
The Dell EMC PowerEdge XE8640 is a supercharge your compute performance with a 2 socket, 4U system designed to optimize the latest industry technologies. Drive AI, HPC and analytics workloads with superior performance. With 4 NVIDIA® HGX H100 80GB 700W SXM5 GPUs, fully interconnected with NVIDIA® NVLink technology
Transform your business
Strike the perfect balance between performance, power and cost when deploying a solution to suit your IT strategy.
- Next generation NVIDIA® GPUs achieve superior AI performance in medical imaging, business decision making applications and most other applications
- Get continuous data processing and faster I/O performance with GPU Direct Storage transfers, bypassing server CPUs
- Scale with confidence thanks to support for up to 32 DDR5 memory DIMM slots, up to eight drives and up to 4 PCIe Gen 5 expansion slots
The Dell PowerEdge XE8640 is a 4U rack server designed for AI and high-performance computing, featuring four NVIDIA HGX H100 80GB 700W SXM5 GPUs, fully interconnected with NVIDIA NVLink. It also includes two 4th or 5th Generation Intel Xeon Scalable processors with up to 64 cores per processor and supports up to 4TB of memory.
Tech Specs & Customization
Processor
- Two 4th Generation Intel® Xeon® Scalable processors with up to 56 cores per processor
Cooling Options
- Air cooling for processors
- Liquid Assisted Air Cooling for GPU (No facility water to rack required)
Operating System
- Canonical® Ubuntu® Server LTS
- Red Hat® Enterprise Linux
Chipset
- Intel® C741 chipset
Accelerators
- 4 NVIDIA® HGX H100 80GB 700W SXM5 GPUs, fully interconnected with NVIDIA® NVLink technology
Memory
- DIMM Speed: Up to 4800 MT/s
- Memory Type: RDIMM
- Memory Module Slots: 32 DDR5 DIMM slots
- Maximum RAM: RDIMM 4 TB max
Storage
- Front Bays: Up to 8 x 2.5-inch NVMe SSD drives, max 122.88 TB
Storage Controllers
- Internal Boot: Boot Optimized Storage Subsystem (NVMe BOSS-N1) with HWRAID 1, 2 x M.2 SSDs or USB
- Software RAID: S160
Security
- Cryptographically signed firmware
- Data at Rest Encryption (SEDs with local or external key management)
- Secure Boot
- Secured Component Verification (Hardware integrity check)
- Secure Erase
- Silicon Root of Trust
- System Lockdown (requires iDRAC9 Enterprise or Datacenter)
- TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Management
- Embedded / At-the-Server: iDRAC9, iDRAC Direct, iDRAC RESTful API with Redfish®, iDRAC Service Module
- Consoles: CloudIQ for PowerEdge plug-in, OpenManage Enterprise, OpenManage Enterprise Integration for VMware® vCenter®, OpenManage Integration for Microsoft® System Center, OpenManage Integration with Windows Admin Center, OpenManage Power Manager plugin, OpenManage Service plugin, OpenManage Update Manager plugin
- Tools: Dell System Update, Dell Repository Manager, Enterprise Catalogs, iDRAC RESTful API with Redfish, IPMI, RACADM CLI
- OpenManage Integrations: BMC Truesight, Microsoft System Center, OpenManage Integration with ServiceNow, RedHat Ansible Modules, Terraform Providers, VMware vCenter and vRealize Operations Manager
Power Supplies
- 2800W Titanium 200-240 VAC or 240 HVDC redundant, hot swap
Fans
- Up to 6 Standard (STD) fans installed in mid tray
- Up to 5 High performance (HPR) gold grade fans installed on the front of the system
- All fans are hot swap
Ports
- Network Options: 1 x OCP 3.0 (optional), 2 x 1GbE LOM (optional)
- Front Ports: 1 x iDRAC Direct (Micro-AB USB) port, 1 x USB 2.0, 1 x VGA
- Rear Ports: 1 x USB 2.0, 1 x USB 3.0, 1 x VGA, 1 x RJ45 iDRAC9 ethernet port
Slots
- 2 CPU configuration: Up to 4 PCIe slots (4 x16 Gen5)
Bezel
- Optional LCD bezel or security bezel
Form Factor
- 4U rack server
Dimensions & Weight
- Height: 6.86 inches (174.3 mm)
- Width: 18.97 inches (481.91 mm)
- Depth: 35.48 inches (901.4 mm) with bezel, 34.07 inches (865.54 mm) without bezel
- Weight: 135.36 pounds (61.4 kg)
