Description

• Two or four 4^th Gen Intel^® Xeon^® Scalable processors
• Up to 16TB DDR5 memory
• Up to 24x 2.5″ SAS/SATA/NVMe drives + 2x 7mm or 2x M.2 drives

• Next-Gen Workload Ready

  The SR850 V3 can scale from two to four 4^th Gen Intel^® Xeon^® Scalable processor family CPUs and up to two enterprise-grade GPUs. It also supports 33% more* direct connections, with Gen4 and Gen5 ready NVMe drives, and plenty of storage expansion options.

  High Performance in a 2U Form Factor

  The Lenovo ThinkSystem SR850 V3 supports more CPU cores*, 4TB more of the newest DDR5 memory for superior computing power.

  Extreme RAS and Superior Security

  The SR850 V3 is at the top of RAS (Reliability, Availability, and Serviceability) list. Features like Predictive Failure Analysis, error detection, self-healing, and light path diagnostics easy for failure identification. XClarity provides simple and standardized management. ThinkShield protects your business with each offering, from development through disposal.

  Tech Specs

  Form Factor

  2U rack

  Processor

  • Two or four 4th Gen Intel^® Xeon^® Scalable processors, up to 350W
  • Mesh topology with 3x UPI links
  • With Up to 4x QAT, DLB, IAA and DSA Accelerators

  GPU Support

  Up to 2x double-width 350W GPUs or 4x single-width 75W GPUs

  Memory

  Up to 16TB of TruDDR5 memory in 64x slots; Memory speeds up to 4800MHz

  Drive Bays

  Up to 24x 2.5″ drives; Supports up to 24x direct connection NVMe drives; 2x 7mm or 2x M.2 drives for boot

  Expansion Slots

  • Up to 12x (8x Gen5 + 4x Gen4) or 7x (6x Gen5 + 1x Gen4) or 12x Gen4 or 9x Gen4 expansion slots
  • Front: VGA, 1x USB 3.1, 1x USB 2.0
  • Rear: 2x USB 3.1, optional Serial port, VGA port, 1GbE dedicated management port

  Network Interface

  2 Dedicated OCP 3.0 slots supporting 1GbE, 10GbE, 25GbE or 100GbE

  HBA/RAID Support

  Support for ThinkSystem PCIe RAID/HBA cards

  Power

  2x Platinum or Titanium hot-swap power supplies; N+N redundancy supported

  High Availability

  PFA; hot-swap/redundant drives and power supplies; redundant fans; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port; optional External Diagnostics Panel Handset with LCD display

  Security

  Root of Trust (RoT) module includes Platform Firmware Resiliency (PFR), Trusted Platform Module (TPM) 2.0 or TCM for PRC and optional Chassis Intrusion Switch. Secures and authenticates the system to prevent unauthorized intrusion.

  System Management

  Lenovo XClarity Controller; Redfish support

  OS Support

  OS Support Microsoft, Red Hat, SUSE, VMware. Visit lenovopress.com/osig for more information

  Limited Warranty

  1-year and 3-year customer replaceable unit and onsite service, next business day 9×5; optional service upgrades.
